MSI PRO Z890-S (Wi-Fi 7) DDR5 Black (Intel Core Ultra LGA1851 Socket) ATX Motherboard #PRO Z890-S WIFI
Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel XMP 3.0
Memory Max.
256GB
Optane Memory Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
3
M.2/SSD Expansion Slot Details
3 x M.2 Slot (1 x M.2 type 2280/2260/2242 supports up to PCIe 5.0 x4, 1 x M.2 type 2280/2260/2242 supports up to PCIe 4.0 x4, 1 x M.2 type 2280/2260/2242 supports up to PCIe 4.0 x4 / SATA)
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
Multi-GPU Support
No
PCI Express Slot
4 x PCI-E x16 slot
Audio & Video
Audio Chipset
Realtek ALC897 Codec
Audio Channel
7.1
Network & Connectivity
LAN Chipset
Realtek 8125D
LAN Speed (Mbps)
100/1000/2500 Mbps
WiFi
Yes
WiFi Technology
Wi-Fi 7
Bluetooth
Bluetooth 5.4
Ports
USB Port
4 x USB 5Gbps Type-A, 1 x USB 20Gbps Type-C, 2 x USB 5Gbps Type-A
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
1
TPM Port
Yes
COM Port
No
Technical Info
Back-Connect Design
No
Cable Management
Front
Heatsink
Yes
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0 , 1 , 5, 10 (SATA), 0 , 1 , 5 (M.2)
RGB Support
ARGB
RGB Connector
3 x Addressable V2 RGB LED connector (JARGB_V2), 1 x RGB LED connector(JRGB)
Approx. Power Consumption
70W
Form Factor
ATX
Compatibility
Supported Operating System
Windows 11
Compatible Products
Compatible with LGA1851 Core Ultra Processors (Series 2)
Warranty
Warranty Details
3 year
Additional Info
Feature
The latest wireless solution with a new 320MHz channel, achieving a maximum transmission speed of 5.8Gbps, which is 2.4 times faster than Wi-Fi 6/6E, Lightning USB 20G, Latest DDR5 Memory, Lightning Gen 5, 2.5G Network Solution, Extended Heatsink Design, M.2 Shield FROZR, Pre-installed I/O Shielding, Frozr AI Cooling.
Others
1 x HDMI 2.1 maximum resolution of 4K 60Hz, 1 x DisplayPort 1.4, maximum resolution of 4K 60Hz, Thunderbolt 4 port supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz/8K@60Hz, Internal Connector: (1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH)).
Country Of Origin
Taiwan
Made in/ Assemble
China
