Gigabyte Z790 AORUS ELITE DDR4 Intel Gaming Motherboard
Product Id: 02.01.018.474
Brand
Gigabyte
Regular Price Tk 39,060
Monthly EMI Tk 3,255
Special Price Tk 36,200
Quick Overview
- Chipset - Intel Z790
- Memory Max. - 128GB
- Memory Slot - 4
- Sockets Supported - LGA1700
- Supported CPU - 12th / 13th / 14th Generation Intel Core i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Gold processors/ Intel Celeron processors.
- Generation - 12th/13th/14th
General
Brand
Gigabyte
Model
Gigabyte Z790 AORUS ELITE
Body Color
Black
CPU
Chipset Brand
Intel
Chipset
Intel Z790
Sockets Supported
LGA1700
Built-in Processor
No
Supported CPU
12th / 13th / 14th Generation Intel Core i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Gold processors/ Intel Celeron processors.
Generation
12th/13th/14th
Memory Support
Memory Type
DDR4
Memory MHz
5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz ECC & non-ECC Un-buffered
Memory Channel
Dual
Memory Slot
4
Memory Slot (Additional Info)
4 x DDR DIMM
Memory Max.
128GB
Memory Max. (Additional Info)
Up to 128 GB (32 GB single DIMM capacity)
Optane Memory Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
4
M.2/SSD Expansion Slot Details
4 x M.2 (1 x M.2 M key type 22110/2280 support PCIe 4.0 x4/x2 SSD), (2 x M.2 M key type 22110/2280 support PCIe 4.0 x4/x2 SSD), (1 x M.2 M key type 22110/2280 support SATA and PCIe 4.0 x4 SSD)
Graphics
Graphics
Integrated
Graphics Chipset
Intel HD Graphics support
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEx16), 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEx4_1) & 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEx4_2)
Audio & Video
Audio Chipset
Realtek Audio CODEC High Definition Audio
Audio Channel
2/4/5.1/7.1
Network & Connectivity
LAN Chipset
Realtek 2.5GbE LAN chip
LAN Speed (Mbps)
10/100/1000/2500 Mb/s
WiFi
No
Bluetooth
No
Ports
USB Port
1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1, 4 x USB 2.0 Type-A
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
No
IDE Port
No
SATA Port
4
Thunderbolt
No
TPM Port
1
COM Port
No
Technical Info
DirectX Support
No
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 5, 10
RGB Support
RGB
RGB Connector
2 x RGB LED strip headers
Approx. Power Consumption
70W
Form Factor
ATX
Bios Information
BIOS Type
1 x 256 Mbit flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Compatibility
Supported Operating System
Windows 10/ 11
Compatible Products
Intel Core i9/ i7/ i5/ i3, Pentium, Celeron processors. (12th/13th/14th Gen) LGA1700 socket.
Warranty
Warranty
3 Year
Warranty Details
3 year
Additional Info
Feature
ASCEND THE THRONE OF GAMING, UNPARALLELED PERFORMANCE, OUTSTANDING THERMAL DESIGN
Others
Memory - Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (xMP) memory module, Onboard Graphics - 1 x HDMI port, supporting a maximum resolution of 4096x2160 at 60 Hz, Internal I/O Connectors - 2 x Thunderbolt??? add-in card connectors, 1 x 24-pin ATX main power connector, 2 x 8-pin ATX 12V power connectors, 1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers, 1 x system fan/water cooling pump header, 2 x addressable LED strip headers, 1 x front panel header, 1 x front panel audio header, 2 x Thunderbolt1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 1 x reset button, 1 x Q-Flash Plus button, 1 x Clear CMOS button, 1 x reset jumper, 1 x Clear CMOS jumper, Back Panel Connectors - 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 2 x audio jacks, I/O Controller - iTE I/O Controller Chip add-in card connectors, H/W Monitoring - Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control, BIOS - PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0,
Country Of Origin
Taiwan
Made in/ Assemble
China
